Chapter One APPLICATIONS Figure 1-44 Cutaway View of Contact-Molded Pipe [Cheremisinoff, Fiberglass- Reinforced Plastics Deskbook] Table 1-7 FRP Pipe Resin Systems [Cheremisinoff, Fiberglass-Reinforced Plastics Deskbook ] Resin Application Isophthalic Mild corrosives at moderate temperatures and general acid wastes Furmarated bi-sphenol Mild to severe corrosive fluids including A-type polyester many alkalies and acids Fire-retardant polyester Maximum chemical resistance to acids, alkalies and solvents Various thermoset resins High degree of chemical resistance to specific chemicals High-quality epoxy Extremely high resistance to strong caustic solutions Extremely high resistance to organic Vinyl ester and proprietary resin systems solvents operating in excess of 350oF acids, oxidizing acids, alkalis and specific The joining of FRP pipe to other materials, such as steel, can be accomplished using a simple flange to flange mate; with an encased concrete system that utilizes thrust rings; or with a rubber expansion joint, as shown in Figure 1-45. For straight FRP connections, an O ring seal can be used. Figure 1-45 In [Cheremisinoff, Fiberglass-Reinforced Plastics Deskbook] 51 Typical Expansion Joint Tie-PDF Image | Marine Componsites
