8 CON E BOTTOM STANDS PART NUMBER DESCRIPTION WEIGHT DIMENSIONS (DIA X HEIGHT) CLEARANCE CB036-45ST 150 GAL – 45o 63 64 X 61 12" CB042-45ST 200, 300 OR 350 GAL – 45o 82 41 X 34 11" CBFD042-45ST 240 GAL FULL DRAIN – 45o 82 42 X 42 10" CB052-45ST 345 OR 500 GAL – 45o 174 55 X 41 13" CB064-15ST 1005 OR 1500 GAL – 15o 320 64 X 25 16” CB064-45ST 1000 OR 1490 GAL – 45o 320 64 X 61 14" CB086-15ST 800 OR 1700 GAL – 15o 360 86 X 23 11" CB086-45ST 2600 GAL – 45o 580 86 X 49 12" CB090-15ST 850, 1000, 1150, 1200, 1300, 2450, 2500 OR 3000 GAL – 15o 380 90 X 24 11" CB090-30ST 1550, 1600, 2550 OR 2600 GAL – 30o 640 94 X 40 9" CB096-30ST OC1010-64 CB096-30ST 1500, 2000, 3000 GAL – 30o 553 96 X 38 12" CB102-15ST 4600 OR 4900 GAL – 15o 640 102 X 25 11" CB122-15ST 4200, 6000, 6900 OR 8250 GAL – 15o 1020 122 X 27 10" CONE BOTTOM TANKS - OPEN TOP All tanks come with bolt-on top Open Top Tanks are selected for collection systems, temporary liquid storage or as secondary containment for tanks in indoor or outdoor stationary installations. Tanks require stands to support the conical bottoms. Tanks are manufactured from medium- or high-density polyethylene with UV inhibitors. Tank walls are translucent for level viewing and equipped with gallon indicators. PART NUMBER DESCRIPTION WEIGHT DIMENSIONS (DIA X HEIGHT) OVERALL HEIGHT FITTINGS SPECIFIC GRAVITY OC0840-90 840 GAL – 15o 214 91 X 49 OC1010-64 1,010 GAL – 45o 252 64 X 99 113" 2" 1.7 61" 2" 1.7 OC1050-90 1,050 GAL – 15o 242 91 X 57 69" 2" 1.7 OC1150-90 1,150 GAL – 15o 262 91 X 60 72" 2" 1.7 OC1450-90 1,450 GAL – 30o 286 91 X 79 89" 2" 1.7 OC1500-64 1,500 GAL – 45o 342 64 X 134 147" 2" 1.7 OC1710-86 1,710 GAL – 15o 286 86 X 87 98" 2" 1.7 OC2350-90 2,350 GAL – 15o 437 91 X 106 118" 2" 1.7 OC2440-90 2,440 GAL – 30o 502 91 X 117 127" 2" 1.7 OC2610-86 2,610 GAL – 45o 502 86 X 147 158" 2" 1.7 STAND IS REQUIRED CONE BOTTOM TANKS - OPEN TOP STANDS PART NUMBER DESCRIPTION WEIGHT DIMENSIONS (DIA X HEIGHT) CLEARANCE CB064-45ST Warning: Cancer and Reproductive Harm. www.P65Warnings.ca.gov 1010 OR 1500 GAL – 45o 320 64 X 61 14" O C1710 - 8 6 CB086-15ST 1710 GAL – 15o 360 86 X 23 11" CB086-45ST 2610 GAL – 45o 580 86 X 49 12" CB090-15ST 840, 1050, 1150, OR 2350 GAL – 15o 380 90 X 24 11" CB090-30ST 1450 OR 2440 GAL – 30o 640 90 X 40 9" CONE BOTTOM TANKS & STANDSPDF Image | Blow Molding Injection Molding Rotational
